NC hydraulic pipe bending machine – Longbo bending machine

The NC hydraulic pipe bending machine is equipped with hydraulic control pipe bending,which is easy to program and operate.The series of hydraulic pipe bending machine is not only easy tooperate,9 bending angles can be set in each gear,and it has the advantages of high precision,low cost.It can be used flexibly for the needs of small and medium-sized production.

Model	Unit	NC38	NC50	NC65	NC65	NC76	NC90	NC110	NC130	NC168	NC219	NC273
Maximum bending capacity	mm	φ38×1.8	φ50×2.0	φ65×2.5	φ65×2.5	φ75×2.5	φ89×2.5	φ110×5.0	φ130×5.0	φ168×16.5	φ219×16	φ270×20
Round tube/stainless steel tube	mm	φ38×1.2	φ50×1.3	φ65×1.6	φ65×1.6	φ75×1.9	φ89×1.5	φ110×2.0	φ130×2.5	①168×4.0	φ219×14	φ270×14
Square tube/metal	mm	30×1.5	40×1.8	50×2.3	50×2.3	60×2.5	75×2.5	90×2.0	90×6.0	110×6.5	189×14	200×14
Bending radius range	mm	25~150	30~230	30~320	30~320	40~250	40-250	50-280	80~500	90-~500	120~800	130~1000
Bending radius range/Square tube	mm	25-130	30-19	35~210	35~210	40-240	45~105	50~300	80~430	90~410	120~801	130~1000
Bending angle range	degree	190	190	190	190	190	190	190	190	190	190	190
Maximum effective distance	mm	3200	2200	3200	3200	4000	4000	4000	5000	6000	1400	6000
Workbench height	mm	1100	1100	1100	1100	1125	1100	1250	1300	1400	1400	1400
Mold center line height	mm	28	40	50	50	55	65	80	90	120	165	185
Bending [B.0.D]speed	deg/sec	120	120	110	110	110	75	75	70	38	38	28
Bending [B.O.D]precision	degree	±0.1	±0.1	±0.1	±0.1	±0.1	±0.1	±0.1	±0.1	±0.1	±0.1	±0.4
Hydraulic system motor	kw	2.2	3.8	5.5	5.5	11	15	22	22	30×2	45×2+11	55×2+11
Machine width	mm	900	900	1150	1150	1500	1500	1700	2000	2200	2300	3400
Machine height	mm	1300	1300	1400	1400	1400	1500	2100	2100	2300	2300	2700
Machine length	mm	4300	4300	5800	5800	6800	6800	7000	9000	10000	11000	11500
Machine weight	kg	850	1600	2800	2800	3000	6200	8200	11000	22000	33000	55000
